SBTM200 series
SBTM200 Series
SBTM200 Series Description:
THB SBTM200 series Pillow block bearings typically consist of a housing, bearing, seal, lubricant and shaft locking mechanism. The units are preassembled and adjusted at the factory. These ready-to-mount units are available with either ball or roller bearings. Housing Materials: HT200, 440C, 420C, 304, ductile iron are available. Insert bearing Materials: GCr15, 440C, 420C are available.
Product List
Bearing Unit No.Shaft Dia
(d) (in)
Shaft Dia
(d) (mm)
Dimensions (a)
(mm)
Dimensions (e)
(mm)
Dimensions (i)
(mm)
Dimensions (g)
(mm)
Dimensions (l)
(mm)
Dimensions (s)
(mm)
Dimensions (b)
(mm)
Dimensions (n)
(mm)
Dimensions (z)
(mm)
Dimensions (B)
(mm)
Bolt Used
(mm)
Bolt Used
(in)
Bearing No.Housing No.Housing (Wt
) (kg)
SBTM201-8 1/2 81 63.5 10.5 10.7 19 7 52 26.5 22 6 M6 1/4 SB201-8 TM203 0.1
SBTM202-9 9/16 81 63.5 10.5 10.7 19 7 52 26.5 22 6 M6 1/4 SB202-9 TM203 0.1
SBTM202-10 5/8 81 63.5 10.5 10.7 19 7 52 26.5 22 6 M6 1/4 SB202-10 TM203 0.1
SBTM203-11 11/16 81 63.5 10.5 10.7 19 7 52 26.5 22 6 M6 1/4 SB203-11 TM203 0.1
SBTM201 12 81 63.5 10.5 10.7 19 7 52 26.5 22 6 M6 1/4 SB201 TM203 0.1
SBTM202 15 81 63.5 10.5 10.7 19 7 52 26.5 22 6 M6 1/4 SB202 TM203 0.1
SBTM203 17 81 63.5 10.5 10.7 19 7 52 26.5 22 6 M6 1/4 SB203 TM203 0.1
SBTM204-12 3/4 90.5 71.40 10.9 11 19.8 8.70 62 28.9 25 7 M8 5/16 SB204-12 TM204 0.23
SBTM204 20 90.5 71.40 10.9 11 19.8 8.70 62 28.9 25 7 M8 5/16 SB204 TM204 0.23
SBTM205-14 7/8 95.2 76.7 11.1 11 19.8 8.70 72 30.5 27 7.5 M8 5/16 SB205-14 TM205 0.3
Total 3 Page 21 Records 123
