7XXX series
> > > > >
7XXX Series
7XXX Series Description:
THB 7XXX series Angular contact ball bearings have inner and outer ring raceways that are displaced relative to each other in the direction of the bearing axis. This means that these bearings are designed to accommodate combined loads, i.e. simultaneously acting radial and axial loads.
Product List
Designations (Universally
matchable bearing)
Designations (Basic
design bearing)
Principal dimensions
(d) (mm)
Principal dimensions
(D) (mm)
Principal dimensions
(B) (mm)
Basic load ratings
(dynamic) (C) (KN)
Basic load ratings
(static) (C0) (KN)
Fatigue load
limit (Pu)
(KN)
Speed ratings
(Reference speed)
(r/min)
Speed ratings
(Limting speed)
(r/min)
Mass (kg)
7200 BECBP 7200 BEP 10 30 9 6.8094 3.2495 0,14 30 000 30 000 0,03
7201 BECBP 7201 BEP 12 32 10 7.3817 3.686 0,16 26 000 26 000 0,036
– 7301 BEP 12 37 12 10.282 4.85 0,208 24 000 24 000 0,06
* 7202 BECBP – 15 35 11 8.536 4.5105 0,196 26 000 26 000 0,045
– 7202 BEP 15 35 11 8.070399 4.268 0,183 24 000 24 000 0,045
7302 BECBP 7302 BEP 15 42 13 12.61 6.499 0,28 20 000 20 000 0,08
* 7203 BECBM – 17 40 12 10.67 5.6745 0,25 22 000 22 000 0,065
* 7203 BECBP – 17 40 12 10.67 5.6745 0,25 22 000 22 000 0,065
– 7203 BEP 17 40 12 10.088 5.335 0,236 20 000 20 000 0,065
– 7203 BEY 17 40 12 10.767 5.917 0,26 20 000 20 000 0,065
Total 22 Page 215 Records 1234567891011 End
