22XX&23XX series
22XX&23XX Series
22XX&23XX Series Description:
THB Self-aligning ball bearings have two rows of balls, a common sphered raceway in the outer ring and two deep uninterrupted raceway grooves in the inner ring. Available with open or sealed version. Available with cylindrical bore and tapered bore. Available with steel cage, nylon cage, brass cage and ceramic cage. Rings and balls material: GCr15, silicon nitride, zirconia or silicon carbide, stainless steel.
Product List
Designations Bearing with
cylindrical bore (a)
Designations Bearing with
cylindrical bore (b)
Principal dimensions
(d) (mm)
Principal dimensions
(D) (mm)
Principal dimensions
(B) (mm)
Basic load ratings
(dynamic) (C )
(KN)
Basic load (ratings
staic) (C0) (KN)
Fatigue load
limit (
Pu)
"Speed ratings
(Referencespeed) (r/min)"
Mass (kg)
2200 E-2RS1TN9 10 30 14 5.3641 1.1446 0,06 17 000 0,048
2201 E-2RS1TN9 12 32 14 6.0528 1.3871 0,08 16 000 0,053
2202 E-2RS1TN9 15 35 14 7.1877 1.7072 0,09 14 000 0,058
2302 E-2RS1TN9 15 42 17 10.476 2.522 0,14 12 000 0,11
2203 E-2RS1TN9 17 40 16 8.5748 2.134 0,12 12 000 0,089
2303 E-2RS1TN9 17 47 19 1.649 3.298 0,18 11 000 0,16
2204 E-2RS1TN9 20 47 18 12.319 3.298 0,18 10 000 0,14
2304 E-2RS1TN9 20 52 21 13.871 3.88 0,21 9 000 0,21
2205 E-2RS1TN9 2205 E-2RS1KTN9 25 52 18 13.871 3.88 0,21 9 000 0,16
2305 E-2RS1TN9 2305 E-2RS1KTN9 25 62 24 18.43 5.238 0,28 7 500 0,34
Total 3 Page 24 Records 123
